The Quality Edge

TOTAL QUALITY ASSURED PROFUCT (TQAP) ‘Avonplast’ Rigid PVC Conduits and fittings have stood the rest of time in ever maintaining its quality standards to the outmost satisfaction and the needs of the end-user, thus gaining the acceptability & trust in ‘Avonplast’ brand of conduits and fittings.

Physical & Electrical properties

'Avonplast' Rigid PVC Conduits have the following properties

Specific gravity 1.4
Tensile trength kg/cm2 Over 500
Breakdown Voltage KV/mm 18
Insulation Resistance 4x10 - @ 500V (40,000 Mega Ohms)

The User Friendly & Convenient product

Easy wiring

'Avonplast' Rigid PVC Conduits have smooth
interior wall which makes wiring easier and faster.

Easy installation

'Avonplast' Rigid PVC Conduits can be shaped and joined without difficulty. Bends can be made by heating. Joining by solvent cement technique is cheaper, simpler and easier.

No maintenance

PVC Conduit pipes do not need any painting and has excellent weathering properties. Hence 'Avonplast' Rigid PVC Conduits need little or no maintenance.

The Standardization

'Avonplast' Rigid PVC Conduits conform to IS : 9537 : 1983 and are available with ISI mark under License no. CM/L - 1325538.'avonplast' Rigid PVC Conduits are made from best quality raw materials and also conform to ASTM-D standards for HIGH IMPACT and Fire retardant low smoke (FRLS).

Range of Products

'Avonplast' Rigid PVC Conduit pipes and Junction boxes are available with Rigid PVC fittings in Grey and Black coours in the range of 16mm. to 63mm.

DIMENSIONAL DETAILS OF RIGID NON-METALLIC CONDUITS

Clause 3.1 IS: 9537/1983 Part -3 with ISI Mark ( All dimensions in millimeters) Note : All sizes with ISI Certified Mark under ISI Marking License no. CM/L 1325538

Nominal O.D. Minimum I.D. Light Medium Heavy Maximum Permissible Eccentricity Maximum Permissible Ovality
16 15.7 13.7 13.0 12.2 0.2 0.5
20 19.7 17.4 16.9 15.8 0.2 0.5
25 24.6 22.1 21.4 20.6 0.2 0.5
32 31.6 28.6 27.8 26.6 0.2 0.5
40 39.6 35.8 35.4 34.4 0.2 0.5
50 49.5 45.1 44.3 43.2 0.4 0.6
63 62.4 57.0 - - 0.4 0.8
